ORDER GUIDE:

Without Webrtc: support 1~3s latency

With Webrtc: support about 300ms latency

3U Rack 16-Channel (With Webrtc): support about 300ms latency

OVERVIEW

In a fast changing and highly competitive TV market, operators and TV service providers must deliver access to content on all screens, anytime, anywhere, while also reducing complexity and driving efficiency across all platforms.

The OTV-E114 high-definition encoder has the functions of encoding , and it can be used for multiple purposes. The HDMI video source can be encoded and compressed into a network stream, and the long-distance high-definition video transmission/live broadcast can be realized on the Internet or a local area network through a wired network.

Main Features

The powerful streaming media service function not only supports general protocols such as RTSP/RTMP, but also other customizable protocols such as Security Onvif and GB28181.

• Support web browser web-side network management login encryption function

• Support HTTP/RTSP/RTMP(S)/HLS/UDP/ONVIF/SRT/RTP/Unicast/Multicast and other international common streaming media service protocols, support Customizable optional NDI HX protocol.

• Supports four-stream output, the main stream is up to 1080p 60FPS video encoding, the sub-stream supports 720p 60FPS video encoding, and the output resolution can be customized.

• Support the construction of a small local area network distribution system, 5-7 display terminals pull streaming playback

• Support private protocol transmission

• Compatible with Wowza/FMS/RED5 and other streaming media servers, and cooperating with streaming media servers to push DC to realize live video, Provides a more reliable encrypted transmission method, and a variety of encryption methods are available.

• Support web browser web-side network management login encryption function

• Support RTMP upload to add user name and password function, RTSP support to enable authentication to add user name and password encryption function

• Support P2P protocol point-to-point independent transmission? High integration, multi-purpose, multi-stream, recording functions.

• Support 4 kinds of code stream output, 4 kinds of different network protocols to transmit at the same time, 4 kinds of resolution/code rate adjustable

• Support key recording function, TF card/USB interface to record TS stream

• Support H.264/H.265 independent decoding HDMI output

• Support video real-time loop-out function, local live broadcast monitoring without delay

• Customizable optional POE power supply module

• Support 1 channel 3.5mm independent audio capture input and 1 channel 3.5mm audio output. Support audio gain/volume adjustment, Strong bandwidth adaptability, stable in low-bandwidth network environment Transmission of high-definition, low-latency, no-stutter audio and video signals.

• Embedded chip and H.265/H.264 video encoding technology, combined with image enhancement technology processing, realize low bit rate encoding to ensure high definition Image quality output, output resolution can be adjusted

• Wider adjustable bit rate, 16Kbit/s～30Mbit/s adjustable, support bit rate control CBR/VBR

• Support DHCP to obtain IP automatically (off by default, some computers will be blocked by firewall)

• The transmission mode supports TCP, UDP, 1000M (full duplex mode)? Low power consumption, low heat dissipation, support 7*24 h uninterrupted operation

• Low power consumption design

• Support Chinese and English OSD, support OSD scrolling, image overlay, XY axis, font can be set, support adding company logo

• Support WEB page access in Chinese and English, change password, support WAN remote management (WEB)

• Support one-key restore, version upgrade and remote maintenance, support one-key restore default configuration

• Support no video signal encoding, the setting will take effect immediately, no need to restart;

Technical Specifications
