Video parameters

Input resolution

1080P:1920*1080@60/50Hz; UXGA: 1600*1200@60Hz;

SXGA: 1280*1024@60Hz; 720P:  1280*720@60/50Hz;

XGA:1024*768@60Hz

Output resolution (loop out)

1080P:1920*1080@60/50Hz; UXGA: 1600*1200@60Hz;

SXGA: 1280*1024@60Hz; 720P:  1280*720@60/50Hz;

XGA:1024*768@60Hz

Encoding Parameters

Encoding type: H.265 Main Profile; H.264 Baseline/Main/High Profile

Bit rate frame rate: Support CBR/VBR, Bitrate adjustable 32Kbps~16Mbps

Frame rate: 1-60fps

Video encoding capability: Dual stream: 1ch 1080p@60fps+1ch VGA@30fps

Audio encoding capability: AAC-LC, G.711a

Other Functions

Audio and video transmission: Support RTSP, RTMP,  Onvif, HTTP, UDP/Multicast, P2P

Data Transparent Transmission: Supports two-way  transparent transmission of serial data

through the network

Video storage: Support MP4 format video storage

Support loop recording

Device management: Built-in webserver, which can  be managed and configured through a browser

Support network remote firmware upgrade

Peripheral interface

Video input: 1*HDMI interface

Video loop out: 1*HDMI interface

Audio interface: 1*input, 1*output, 3.5mm  interface (level: 2.0Vp-p, impedance: 1KΩ),

supports embedded audio

Wireless network: support wireless network  transmission, built-in WiFi module

Serial interface: 1*RS232 serial data or 1*RS485  communication interface as per order

Local storage: 1 TF card slot (support 128GB TF  card storage)

Management

Configuration Interface: web-based UI

Upgraded: via network

Connector: RJ45, 10/100M Ethernet interface

The Working Environment

Dimension

Rack 125x 75x23mm

Gross Weight

0.13/0.325KG

Temperature

0 to 45  (For working), -20 to 80(For storing)

Input Voltage

DC5.5/2.1  interface DC12V

Power Consumption

5W
